16×2 Character LCD Module Blue Background

16×2 Character LCD Module Blue Background

200.00 180.00

Compare

Description

ERM1602SBS-6 is 16 characters wide,2 rows character lcd module,SPLC780C controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with white color included can be dimmed easily with a resistor or PWM,stn- blue lcd negative,white text on the blue color,wide operating temperature range,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set.Optional 3.3v or 5v power supply and optional pin header connection.

It’s easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment.

No.   Name  Description
1 VSS Mass
2 VDD Power supply + 5V
3 V0 Contrast
4 RS Selection of the display instruction register

(low state) or data register (high)

5 R / W Read (low state) / Record (high state)
6 E Unlocking the display
7 DB0





Data bus.

8 DB1
9 DB2
10 DB3
11 DB4
12 DB5
13 DB6
14 DB7
15 LEDA Backlight supply + 5V
16 LEDK Backlight weight
